Home Bottle washer SK-400W-80L-12V/24V/48V-2

SK-400W-80L-12V/24V/48V-2

  • Self-Priming
  • Can run dry for long time
  • Suction:2.5-3M
  • Heat resistant 60°C
  • Can keep working for long time
Materialattachliquid:

Flow Rate:80.00 LPM

Add to Inquiry

Product detail

Various diaphragms can be replaced to extract different fluids

TPV valve diaphragm

Nitrile valve diaphragm

Fluoroplastic valve diaphragm

Material attaches the liquid:

PP/TPV/Viton-F      suitable for : Acid and alkaline chemical solution

PP/TPV/EPDM      suitable for : Adblue,light corrosion

    Popular applications:



    Product specification

    Voltage Flow Rate Head Control Method Max.Amps Setting Pressure Inlet/Outlet
    DC 12V 65LPM 20M Pressure switch 46A 0.3Mpa 1.2" Pipe thread
    DC 24V 65LPM 20M Pressure switch 25A 0.3Mpa 1.2" Pipe thread
    DC 48V 65LPM 20M Pressure switch 12.5A 0.3Mpa 1.2" Pipe thread
