Material attaches the liquid:
PP/TPV/Viton-F suitable for : Acid and alkaline chemical solution 100LPM
PP/TPV/EPDM suitable for :Fleshwater 80LPM
Featrures:
1.Self-Priming
2.Can run dry for long time
3.Suction:2.5-3M
4.Heat resistant 60°C
5.Can keep working for long time
| Voltage | Flow Rate | Head | Suction | Max.Amps | Mterial attach the liquid | Inlet/Outlet |
|---|---|---|---|---|---|---|
| DC 24V | 100LPM | 20M | 25M | 15A | EPDM,Santoprene,PP | 1.2" Pipe thread |
| DC 24V | 80LPM | 20M | 25M | 15A | Viton-F,Santoprene,PP | 1.2" Pipe thread |
Filling machine |
Liquid transfer |
Cleanning or spraying |
